MCF88 LoRa MCF88 LoRaWAN Multi Multi I/O Module

LoRa MCF88 LoRaWAN Multi Multi I/O Module LoRaWAN® Multi I/O moduleThis device transmits the state of its 16 inputs and controls 8 outputs through the LoRaWAN® network. All these inputs and outputs are galvanically isolated. It can be used for industrial process control, home automation, water treatment, agriculture irrigation and similar applications.Technische Daten:- CPU Cortex M0- RTC- EEProm 32KB- Flash 96KB- Encryption AES 128 bit- Class C LoRaWAN®™ stack EU868, AS923- 16 opto-isolated input AC-DC, range 5-24Vac/dc- 8 relay output with COM, NO, NC contacts carrying 5Amp@230Vac- USB port for IoT node setup ad FW upgrade- CANBUS interface- Power supply 24 Vac/dc- Storage temperature range -20 + 80C°- Working temperature range -10 + 70C°- DIN (EN 60715) mounting enclosure, 9 modules
