Ubiquiti UniFi Switch USW-Pro-24-POE Gen2 400W PoE

1U rack-mount Layer 3 switch with 24 GbE RJ45 ports and 2 10G SFP+ uplink ports, delivering a total PoE budget of 400 W across 16 PoE+ and 8 PoE++ ports. It integrates into the UniFi platform and is managed via the UniFi Network application version 5.10.5 or later. Key Features Switching performance: 88 Gbps switching capacity and 44 Gbps non-blocking throughput PoE up to PoE++: 400 W available, with 60 W per PoE++ port PSE output LCM touchscreen: built-in 1.3-inch display for local monitoring Power redundancy: DC Power Backup via USP RPS input NDAA compliance: certified to meet NDAA requirements Pro AV: supports Play, Dante, Q-SYS, NDI, SDVoE, Shure, AES67, and Crestron profiles Performance and Throughput The switch delivers 88 Gbps switching capacity and 44 Gbps non-blocking throughput, with a forwarding rate of 65 Mpps. It supports jumbo frames, LACP for port aggregation, and STP and RSTP for loop management. The packet buffer is 2 MB, and the MAC address table can store up to 16,000 entries. Power and PoE The internal 450 W AC/DC power supply provides a total available PoE budget of 400 W. The 16 PoE+ ports deliver up to 30 W per port PSE output, while the 8 PoE++ ports support up to 60 W per port. Maximum power consumption is 50 W without PoE output and 450 W with PoE output. The primary power supply accepts a universal input of 100–240 V AC at 50/60 Hz, and a DC USP RPS input ensures redundancy via DC Power Backup. Thermal dissipation is 170.6 BTU/h without PoE output. Layer 3 Management and Features Management is performed via Ethernet AR and requires UniFi Network version 5.10.5 or later. As a Layer 3 switch, it supports static routing with 2 IPv4 static routes, inter-VLAN routing for local networks, a local DHCP server, and DHCP relay. Up to 1,000 VLANs are supported. IPv4 and MAC access control lists each allow up to 128 entries, and Virtual Network Override is available for enhanced segmentation flexibility. Security and Compliance The switch includes 802.1X control, MAC-based ACLs with device isolation, and IP-based ACLs with network isolation. DHCP Snooping and Guarding, MAC address blocking, MAC-based port restriction, and port isolation are all supported. ESD protection reaches ±16 kV in air and ±12 kV in contact. The product is NDAA-compliant and includes regulatory certifications such as Anatel number 13790-20-08356. Pro AV and Multicast Built-in Pro AV profiles support Play, Dante, Q-SYS, NDI, SDVoE, Shure, AES67, and Crestron. Advanced IGMP configuration includes Querier, Fast Leave, and Router Port, complemented by IGMP Snooping. Storm control, egress rate limiting, multicast and broadcast rate limiting, flow control, port mirroring, LLDP-MED, Voice VLAN, and loop protection are also available. Design and Installation The SGCC steel chassis is designed for 1U rack mounting with dimensions of 442 x 285 x 44 mm. The weight is 4.3 kg without mounting brackets and 4.4 kg with brackets. Supported rack depth ranges from 400 to 1200 mm. The 1.3-inch LCM touchscreen provides local information. The device is designed for reliable operation in typical indoor environments. Technical Specifications PoE+ ports: 16 PoE++ ports: 8 Max PoE power per port (PSE) - PoE: 15.4W Max PoE power per port (PSE) - PoE+: 30W Max PoE power per port (PSE) - PoE++: 60W Maximum power consumption: 50W (without PoE) / 450W (with PoE) Power method: universal input 100–240V AC, 50/60 Hz + DC USP RPS input Power supply: AC/DC, internal, 450W Supported voltage range: 100–240V AC Thermal dissipation: 170.6 BTU/hr (without PoE) Weight: 4.3 kg (without brackets) / 4.4 kg (with brackets) Chassis material: SGCC steel Supported rack depth: 400–1200 mm LCM display: 1.3" touchscreen ESD protection: air ±16kV, contact ±12kV NDAA compliance: yes Certifications: Anatel 13790-20-08356 1 GbE RJ45 ports: 24 (16 PoE+; 8 PoE++) (1G/100M/10M) 10G SFP+ ports: 2 (10G/1G) Max PoE output: up to PoE++ Total available PoE power: 400W Redundancy: DC Power Backup Layer 3: yes Form factor: 1U rack-mount Switching capacity: 88 Gbps Non-blocking throughput: 44 Gbps Forwarding rate: 65 Mpps Supported VLANs: 1,000 MAC table size: 16,000 IPv4 static routes: 2 Packet buffer: 2 MB IPv4 ACLs: 128 MAC ACLs: 128 Application requirements: UniFi Network version 5.10.5 or later Warranty: 12 months
