Poynting · Antennen · 5G/LTE · Mast/Wand · A-EPNT-0002-V3-01 · weiß · SMA (F)

The Poynting ePoynt-2 is an all-in-one outdoor antenna enclosure that houses a compatible router directly inside a rugged housing, eliminating long RF cables and delivering 4×4 MIMO cellular with 11 dBi peak gain alongside 2×2 MIMO dual-band Wi-Fi . It is engineered for fixed wireless access, consumer and industrial 5G/4G deployments, and rural or agricultural data distribution. Highlights at a Glance Integrated CPE design: router sits inside the enclosure for short RF cables and minimal signal loss 4×4 MIMO cellular with 11 dBi peak gain across 617–4200 MHz 2×2 MIMO Wi-Fi covering 2.4 GHz and 5–7.2 GHz with 5 dBi gain Advanced metamaterial (AMC) technology for high gain over main 4G/5G bands Weather, dust, and vandal-resistant enclosure Flexible mounting on pole, wall, or window surfaces Design & Architecture The ePoynt-2 transforms a standard antenna enclosure into high-performance Customer Premises Equipment by integrating the router directly inside the housing. This architecture removes the need for long feeder cables, which are a primary source of RF loss in conventional outdoor installations. Short RG178 cables of 0.25 m connect the antennas to the router, preserving signal strength and contributing to faster data rates. The enclosure accommodates router modules up to 185 × 145 × 45 mm, making it compatible with a range of commercially available cellular routers. Cellular Performance Four cellular ports drive a 4×4 MIMO configuration with a peak gain of 11 dBi, measured at the antenna excluding cable loss. The cellular frequency range spans 617–4200 MHz, covering an extensive set of 5G and LTE bands. On the 5G side, supported bands include n1 through n256, encompassing sub-6 GHz allocations used by operators worldwide. LTE coverage extends across bands B1 through B106, ensuring broad operator compatibility for both urban and rural deployments. The antenna is uni-directional and cross-polarised, which helps maximise reception when aimed toward the serving cell site. Wi-Fi Performance Two dedicated Wi-Fi ports provide a 2×2 MIMO dual-band configuration operating at 2.4 GHz and 5–7.2 GHz. The Wi-Fi antenna element delivers 5 dBi gain in an omni-directional pattern. Supported standards include Wi-Fi 3 (802.11g), Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), and Wi-Fi 6E (802.11ax), covering legacy through current-generation wireless protocols. This allows the enclosure to serve local Wi-Fi access directly from the outdoor-mounted router without a separate indoor access point. Installation & Mounting The enclosure supports pole mount, wall mount, and window mount installations, giving installers flexibility across different site conditions. All RF connections use SMA (F) connectors, matching the interface found on most cellular routers in this size class. The white housing measures 185 × 145 × 45 mm externally and is supplied with 0.25 m RG178 coaxial cables for the short internal run between antenna elements and router ports. Packaged weight is 2.17 kg, with packaged dimensions of 410 × 280 × 177 mm. Environmental & Applications The enclosure is designed for permanent outdoor exposure, providing protection against dust ingress and water jets. Poynting positions the ePoynt-2 for fixed wireless access, consumer 5G/4G internet, industrial and commercial cellular deployment, urban and rural household reception, and agricultural data distribution scenarios. A 24-month warranty accompanies the product. The country of origin is China. Technical Specifications Technology: Cellular (LTE/2G/3G/4G/5G), Wi-Fi Cellular Frequency Range: 617 – 4200 MHz 5G Bands: n1, n2, n3, n5, n7, n8, n12, n13, n14, n18, n20, n25, n26, n28, n29, n30, n34, n38, n39, n40, n41, n48, n53, n65, n66, n67, n71, n77, n78, n80, n81, n82, n83, n84, n85, n86, n89, n90, n95, n97, n98, n100, n101, n106, n256 LTE/4G Bands: B1, B2, B3, B4, B5, B7, B8, B9, B10, B12, B13, B14, B17, B18, B19, B20, B25, B26, B27, B28, B29, B30, B33, B34, B35, B36, B37, B38, B39, B40, B41, B44, B53, B65, B66, B67, B68, B69, B71, B85, B103, B106 Gain (Cellular): 11 dBi peak (excluding cable loss) Cellular MIMO: 4×4 LTE Ports: 4 Cellular Directionality: Uni-Directional Polarisation: X-Polarised Wi-Fi Frequency Range: 2.4 GHz & 5 – 7.2 GHz Wi-Fi Standards: Wi-Fi 3 (802.11g), Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax) Gain (Wi-Fi): 5 dBi (omni-directional) Wi-Fi MIMO: 2×2 Wi-Fi Ports: 2 Connectors: SMA (F) Coax Cable: RG 178 / 0.25 m Mounting Type: Pole Mount, Wall Mount, Window Mount Environmental Rating: Designed for outdoor use with protection against dust and water jets Colour: White Router Housing Dimensions: 185 × 145 × 45 mm Packaged Weight: 2.17 kg Packaged Dimensions: 410 × 280 × 177 mm Master Box Quantity: 6 Master Box Weight: 13.02 kg Master Box Dimensions: 1126 × 430 × 330 mm Warranty: 24 months Country of Origin: CN
