D-Link DWM-314-G 5G NR M2M Multi-Connect Modem€392.34excl. VATRRP €415.13−5%
D-Link DWM-314-G 5G NR M2M Multi-Connect Modem
D-Link DWM-314-G 5G NR M2M Multi-Connect Modem
D-Link DWM-314-G 5G NR M2M Multi-Connect Modem
D-Link

D-Link DWM-314-G 5G NR M2M Multi-Connect Modem

SKU: dwm-314-g|Only 1 ready to ship!

The D-Link DWM-314-G harnesses 5G NR with automatic failover to keep smart parking poles, kiosks and ATMs seamlessly connected to the cellular network, enabling real-time data transfer and remote management. Its four built-in Gigabit Ethernet ports reduce the need for extra power supplies and separate switches, since several endpoint devices can be connected directly to the modem.

Categories
Network & CommunicationNetwork DevicesIndustrial Routers

€392.34excl. VATRRP €415.13−5%

Description

Applications

Highlights

  • 5G NR module delivering up to 3.4 Gbps NSA and 2.4 Gbps SA downlink
  • 4 x Gigabit Ethernet ports for simultaneously connecting several endpoint devices
  • 2 x 3FF Micro-SIM slots for automatic cellular failover
  • OpenVPN and WireGuard support for encrypted data transmission
  • IPS attack prevention and access control for extra network security
  • Centralized remote management via the D-Link D-ECS cloud platform

Technical Overview

  • 4 x external SMA antenna connectors for cellular
  • LTE fallback up to 1.6 Gbps downlink / 200 Mbps uplink
  • Static routing and NAT for connecting multiple local devices
  • Powered via a 2-pin terminal block, DC 9-36V
  • Operating temperature from -30°C to 70°C; DIN-rail mounting supported
  • Managed via Web UI, SMS remote control or the D-ECS cloud

Remote Management with D-ECS

D-ECS lets you monitor every connected 5G multi-connect modem from a single dashboard. The AWS-hosted platform shows connection status, 5G signal quality and data usage in real time, plots sites on Google Maps, and supports scheduled reboots or firmware upgrades outside business hours.

Installation & What's in the Box

Included are four detachable SMA antennas, a wall-mount power adapter, an RJ45 Ethernet cable and a DIN-rail mounting kit.

Downloads

Frequently Asked Questions (FAQ)

How many Ethernet ports does the DWM-314-G have?
4x Gigabit Ethernet LAN ports – more than the DWM-311-G (1 port), suited to several wired end devices at the same site.
Does the DWM-314-G support bridge mode?
No, unlike the DWM-311/-G, the DWM-314-G has no bridge mode, but it does add static route, access control, IPS and WireGuard VPN.
How many SIM cards does the DWM-314-G support?
The DWM-314-G has two 3FF Micro-SIM slots, so the unit can automatically switch to the second SIM if one carrier fails or has poor coverage (failover).
What is D-Link D-ECS (Edge Cloud Service)?
D-ECS is an AWS-hosted, multi-tenant cloud management platform for D-Link's 4G/5G M2M portfolio. It provides a device overview with map view, remote maintenance (reboot, reset, firmware and configuration rollout), scheduled tasks, alerting on status or traffic thresholds, and role-based user management with SAML 2.0 SSO. Using it requires a separate D-ECS license, bound 1 license per device.
Do I need to buy a D-ECS license to use the device?
No. D-Link M2M devices work standalone via the local web interface; basic functions such as remote reboot, firmware upgrade and SNMP are already built in. A D-ECS license (DECS-Y1-LIC/DECS-Y3-LIC) is only needed when several devices are to be managed centrally through one cloud interface.
Do D-Link M2M devices work with eSIM, or only with physical SIM cards?
All D-Link M2M devices listed here (DWM-3xx, DTM-5xx) use physical SIM cards only (Micro- or Nano-SIM, with 1 or 2 slots depending on the model). eSIM support is not documented by the manufacturer for any of these models.
What is the difference between the DTM transit gateways and the DWM modems/routers?
The DTM series (DTM-550-G, DTM-570-GS) is designed for vehicle/rail use: a built-in Wi-Fi 6 access point (AX1800), a GNSS receiver, ignition sensing (IGN) or a rail field bus (RS-232), and a wide voltage input with rail/vehicle certification. The DWM series are more compact industrial modems/routers without GNSS or built-in Wi-Fi 6, designed for stationary control-cabinet deployment.
